About this item
- 1TB Storage Capacity
- PCIe Gen4 x4 NVMe Performance
- Up to 7,000 MB/s Read Speed
- Up to 5,700 MB/s Write Speed
- 3D TLC NAND
- M.2 2280 Form Factor
- 700 TBW Endurance
The CORSAIR MP600 PRO NH uses Gen4 PCIe technology to achieve unbelievably fast sequential read speeds up to 7,000MB/sec and write speeds up to 5,700MB/sec.
Extreme Gen4 Storage Performance – A PCIe Gen4 x4 controller delivers phenomenal read, write, and response times that leave standard M.2 SSDs in the dust.
- Sequential Read/Write Speed Up to 7,000/5,700 MB/s
- Performance and endurance vary by capacity. Reduced performance on Gen3
Your PC Made Faster – Load games, Boot Windows, open and transfer files, all faster than ever.
High-speed Gen4 Pcie X4 NVMe 1.4 M.2 Interface – Leveraging PCIe Gen4 NVMe 1.4 technology for maximum bandwidth, the MP600 PRO NH delivers incredible storage performance.
High-density 3D TLC NAND – Provides the ideal mix of performance and endurance to ensure that your drive will last and perform well through many years of use.
Compact M.2 2280 Form-factor – Fits directly onto most motherboards, making a great upgrade for laptops and notebooks with PCIe Gen4-capable CPUs
Technical Details
| Brand | CORSAIR |
| Model Name | MP600 PRO NH 1TB |
| Model Number | CSSD-F1000GBMP600PNH |
| SSD Unformatted Capacity | 1TB |
| SSD Smart Support | Yes |
| Weight | 0.034kg |
| SSD Interface | PCIe Gen 4.0 x4 |
| SSD Max Sequential Read CDM | Up to 7000MB/s |
| SSD Max Sequential Write CDM | Up to 5700MB/s |
| Max Random Write QD32 IOMeter | Up to 1.1M IOPS |
| Max Random Read QD32 IOMeter | Up to 870K IOPS |
| Power Consumption active | 10.1W Average |
| Form Factor | M.2 2280 |
| Dimensions | Client |
| Application Consumer | MP600 PRO NH M.2 SSD |
| NAND Technology | 3D TLC NAND |
| Voltage | 3.3V, +/- 5% |
| Endurance | 700TBW |
| TBW | 700 |
| MTBF | 1,600,000 Hours |
| DEVSLP | PS4: <3mW |
| Encryption | AES 256-bit Encryption |
| Storage Temperature | -40°C to +85°C |
| SSD Operating Temperature | 0°C to +70°C |
| SSD Shock | 1500 G |
| Storage Humidity | 93% RH (40° C) |
| Operating Humidity | 90% RH (40° C) |
| Vibration | 20Hz~80Hz/1.52mm, 80Hz~2000Hz/20G |
| Warranty | 5 Years |
