About this item
- Transcend 4TB M.2 SSD 830S, SATA III 6Gb/s, 3D NAND Flash with DDR3 DRAM Cache Type 2242 and 2280 Read/Write Speed-up to 560/520 MB/s Internal Solid-State Drive – TS4TMTS830S
- Transcend’s M.2 SSD 830S reaches incredible read and write speeds of up to 560MB/s and 520MB/s.
- 3D NAND flash is a type of flash memory in which the memory cells are stacked vertically in multiple layers.
- Transcend’s M.2 SSD 830S delivers optimal reliability.
- 3D NAND is developed to break through density limitations of the 2D planar NAND, and thus can deliver a greater level of performance and endurance.
- taking up little space while giving it a much needed energy boost.
Made to fit. Ultra compact. SATA III M.2 SSD 830S – Transcend’s ultra-compact SATA III 6Gb/s M.2 SSD 830S addresses the high-performance needs and strict size limitations of small form factor devices, best suited for Ultrabooks and thin, light notebooks3D NAND is developed to break through density limitations of the 2D planar NAND, and thus can deliver a greater level of performance and endurance.the M.2 SSD 830S makes for an easy upgrade to your computer, taking up little space while giving it a much needed energy boost.
Transcend M.2 SSD 830S – Transcend’s ultra-compact SATA III 6Gb/s M.2 SSD 830S addresses the high-performance needs and strict size limitations of small form factor devices, best suited for Ultrabooks and thin, light notebooks. Boasting high-quality flash chips, DDR3 DRAM cache, and enhanced firmware algorithms, Transcend’s M.2 SSD 830S delivers optimal reliability.
Superior transfer speeds – Featuring the M.2 standard (80mm), the next generation SATA III 6Gb/s interface and a powerful controller, Transcend’s M.2 SSD 830S reaches incredible read and write speeds of up to 560MB/s and 520MB/s. When used as a cache, the M.2 SSD 830S provides 1.5 times faster boot time than conventional hard drives.
Store more in less space – Best suited for Ultrabooks and thin, light notebooks. Boasting high-quality flash chips, DDR3 DRAM cache, and enhanced firmware algorithms,3D NAND is developed to break through density limitations of the 2D planar NAND
3D expansion to break through limits – Unlike the existing planar NAND chips, 3D NAND flash is a type of flash memory in which the memory cells are stacked vertically in multiple layers. 3D NAND is developed to break through density limitations of the 2D planar NAND, and thus can deliver a greater level of performance and endurance.
High IOPS to speed up loading times – Dedicated to maximizing high-performance computing, the M.2 SSD 830S features 4k random file read and write speeds up to 90,000 IOPS that deliver incredibly short loading times and almost instant response for heavy graphics and multimedia applications.
Perfect for your Ultrabook – Compliant with M.2 form factors Type 2242 and 2280, Transcend’s 3D NAND M.2 SSDs are perfect for use in Ultrabooks and lightweight notebooks. Measured at just 80mm in length, the M.2 SSD 830S makes for an easy upgrade to your computer, taking up little space while giving it a much needed energy boost
Technical Details
Brand | Transcend |
Model Number | TS4TMTS830S |
SSD form factor | M.2 |
SSD capacity | 4000 GB |
Interface | Serial ATA III |
Memory type | 3D NAND |
NVMe | Yes |
Component for | Notebook |
Hardware encryption | Yes |
Data transfer rate | 6 Gbit/s |
Read speed | 560 MB/s |
Write speed | 520 MB/s |
Random read (4KB) | 90000 IOPS |
Random write (4KB) | 85000 IOPS |
M.2 SSD size | 2280 (22 x 80 mm) |
DevSlp (device sleep) support | Yes |
S.M.A.R.T. support | Yes |
TRIM support | Yes |
ECC | Yes |
Native Command Queuing (NCQ) | Yes |
Mean time between failures (MTBF) | 2000000 h |
Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1 |
Linux operating systems supported | Kernel 2.6.31, Kernel 2.6.33, Kernel 3.12, Kernel 3.17, Kernel 3.3, Kernel 4.6.4, Linux Kernel 5.10, Linux Kernel 5.11, Linux Kernel 5.12, Linux Kernel 5.13, Linux Kernel 5.14, Linux Kernel 5.15, Linux Kernel 5.8, Linux Kernel 5.9 |
TBW rating | 9680 |
Certification | CE/FCC/BSMI/KC/RCM/UKCA |
Operating voltage | 3.3 V |
Operating temperature (T-T) | 0 – 70 °C |
Maximum operating temperature | 70 °C |
Item Height | 70 °C |
Item Width | 70 °C |
Dimensions | 12 x 8 x 6 cm |
Item Weight | 20 Grams |
Warranty | 1 Year |
