About this item
- 32-bit PCIe interface, saving the finite chassis space
- Wake-on-LAN, convenient to manage over LAN+
- 10/100/1000Mbps half-duplex mode
- 20/200/2000Mbps full-duplex mode
- IEEE 802.3x flow control (full-duplex)
- LED status indicators
- 1 x gigabit port
Operating System – Supports operating systems include Windows 10/8.1/8/7/Vista/XP
Low-Profile Bracket – In addition to standard bracket, low-profile bracket is also provided for mini tower computer case
Wake On LAN – Remotely power on/off your computer with WOL, good for centralized management
Technical Details
| Brand | TP-Link |
| Model | Gigabit PCIe Network Adapter |
| Part | 101502028 |
| Color | Silver |
| Compatibility | Windows: XP, Vista, 7 |
| Operating Humidity | Operating: 10 % – 90 % Non-condensing, Storage: 5 % – 90 % Non-condensing |
| Operating Temperature | Operating: 0DegC – 40 DegC, Storage: -40DegC – 70DegC degree C |
| In The Box | Gigabit PCI Express Network Adapter TG-3468, Resource CD |
| LED Indicators | Yes |
| Compliance | |
| Supported Standards | IEEE 802.3, CSMA/CD, IEEE 802.1q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.3x, TCP/IP |
| Type | |
| Wired | Yes |
| Interface | |
| Bus Type | PCI Express 32-bit |
| Port Connection | |
| Connector Support | Auto MDI/MDIX |
| Connector Type | RJ45 |
| Number of Connectors | 1 |
| Speed | 1000 Mbps |
| Transfer Rate | |
| Transfer Rate | 10/100/1000 Mbps (Half-duplex Mode), 20/200/2000 Mbps (Full-duplex Mode) |
| Warranty | |
| Warranty | 1 Year |
